HIKVISION DS-7208HTHI-K2 User Manual

Network Video Recorder User Manual
152
Go to System > Event > Smart Event.
Click Region Exiting.
Region Exiting Detection
Select a camera to configure.
Check Enable Region Exiting Detection.
Optionally, check Save VCA Picture to save the captured pictures of region exiting
detection.
Follow the steps to set the detection rules and detection areas.
1) Select an Arming Region to configure. Up to 4 regions are selectable.
2) Drag the sliders to set Sensitivity.
Sensitivity: The higher the value is, the more easily the detection alarm can be triggered.
Its range is [0-100].
3) Click Draw Region and draw a quadrilateral in the preview window by specifying four
vertexes of the detection region.
Set the arming schedule. Refer to Chapter 11.1 Configure Arming Schedule.
Set the linkage actions. Refer to Chapter 11.2 Configure Alarm Linkage Actions.
Click Apply.

HIKVISION DS-7208HTHI-K2 Specifications

General

Voltage	12 V
Product color	Black
LED indicators	Yes
Channels quantity	8 channels
Maximum frame rate	30 fps
Audio formats supported	G.711
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.265 Pro+, H.265 Pro, H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Playback resolutions supported	8MP/5MP/4MP/3MP/1080p/720p/WD1/4CIF/VGA/CIF
Audio input	4
BNC input ports	8
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	Serial ATA
Number of HDDs supported	2
Power consumption (max)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Optical drive included	No

Weight and Dimensions

Depth	320 mm
Width	380 mm
Height	48 mm
Weight	2000 g
