HIKVISION DS-7208HTHI-K2 User Manual

Network Video Recorder User Manual
182
 Click to view the related video file.
Export the Log Files
Before You Start:
Connect a storage device to your device.
Search the log files. Refer to Chapter 17.2.1 Search the Log Files.
Select the log files you want to export, and click Export.
Or you can click Export ALL on the Log Search interface to export all the system logs to the
storage device.
Export Log Files
Select the storage device from the dropdown list of Device Name.
Select the format of the log files to be exported. Up to 15 formats are selectable.
Click Export to export the log files to the selected storage device.
Related Operation:
 Click New Folder to create new folder in the storage device.
 Click Format to format the storage device before log export.

HIKVISION DS-7208HTHI-K2 Specifications

General

Voltage	12 V
Product color	Black
LED indicators	Yes
Channels quantity	8 channels
Maximum frame rate	30 fps
Audio formats supported	G.711
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.265 Pro+, H.265 Pro, H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Playback resolutions supported	8MP/5MP/4MP/3MP/1080p/720p/WD1/4CIF/VGA/CIF
Audio input	4
BNC input ports	8
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	Serial ATA
Number of HDDs supported	2
Power consumption (max)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Optical drive included	No

Weight and Dimensions

Depth	320 mm
Width	380 mm
Height	48 mm
Weight	2000 g
