Network Video Recorder User Manual
80
Key Point Configuration
1) Configure key point parameters.
Preset: It determines the order at which the PTZ will follow while cycling through the
patrol.
Speed: It defines the speed at which the PTZ will move from one key point to the next.
Duration: It refers to the time span to stay at the corresponding key point.
2) Click Apply to save the key points to the patrol.
(Optional) Click to edit the added key point.
Edit Key Point
(Optional) Select a key point and click to delete it.
(Optional) Click or to adjust the key point order.
Click Apply to save the settings of the patrol.
Repeat steps 3-9 to set more patrols.
Call a Patrol
Purpose:
Calling a patrol makes the PTZ to move according to the predefined patrol path.
