HIKVISION DS-7316HQHI-F4/N User Manual

Digital Video Recorder User Manual
245
Step 7 (Optional) Click Copy to copy the parameters of the current camera to other analog
cameras.
Step 8 Click Apply to save the settings.

The camera parameters settings is only applicable for ananlog cameras.

The 4 MP/5 MP Signal Switch, Defog, Day to Night Sensitivity, Night to Day Sensitivity and IR
Light Brightness functions must be supported by the connected analog camera. You cannot
set the parameters if the connected analog camera does not support them or there is no
video signal.

The parameters are saved to the connected analog camera and are not saved to the DVR.

The default value of Day to Night Sensitivity, Night to Day Sensitivity and IR Light Brightness
is 5. The effective value ranges from 1 to 9.

If you exit from the interface and enter it again, the parameters displayed are those you
have set the last time.

The DVR connects to the analog camera via coaxitron and there is no response mechanism.
Even if the coaxitron is abnormal, the parameters are still displayed to be set successfully.

HIKVISION DS-7316HQHI-F4/N Specifications

General

Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264
BNC input ports	1
Video input channels	16 channels
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Power consumption (typical)	45 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Dimensions (WxDxH)	445 x 390 x 70 mm
