Digital Video Recorder User Manual
39
No. Name Description
interface.
3 REC Button
Enter the Manual Record setting menu.
In PTZ control settings, press the button and then you
can call a PTZ preset by pressing Numeric button.
It is also used to turn audio on/off in the Playback
mode.
4
DIRECTION
Button
Navigate between different fields and items in menus.
In the Playback mode, the Up and Down button is used
to speed up and slow down recorded video. The Left
and Right button will select the next and previous
record files.
In Live View mode, these buttons can be used to cycle
through channels.
In PTZ control mode, it can control the movement of the
PTZ camera.
ENTER Button
Confirm selection in any of the menu modes.
It can also be used to tick checkbox fields.
In Playback mode, it can be used to play or pause the
video.
In single-frame Playback mode, pressing the button will
advance the video by a single frame.
5 PTZ Button
In Auto-switch mode, it can be used to stop /start auto
switch.
6 DEV Enables/Disables Remote Control.
7
Alphanumeric
Switch to the corresponding channel in Live view or PTZ
Control mode.

HIKVISION DS-7316HQHI-F4/N Specifications

General

Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264
BNC input ports	1
Video input channels	16 channels
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Power consumption (typical)	45 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Dimensions (WxDxH)	445 x 390 x 70 mm
