Digital Video Recorder User Manual
50
No.
Item Description
2
VIDEO OUT BNC connector for video output.
CVBS output is not provided by DS-7100/7200HGHI-E1,
DS-7200HGHI-E2, DS-7100/7200HGHI-F1,
DS-7200HGHI-F2, DS-7100HQHI-F1/N and
DS-7100HGHI-F1/N series DVR.
3 AUDIO IN RCA connector
4
USB Port Universal Serial Bus (USB) port for additional
devices.
5
HDMI1/VGA Simultaneous HDMI1/VGA output. Display local
video output and menu.
6 HDMI2 HDMI2 video output connector.
7 AUDIO OUT RCA connector.
8 Network Interface Connector for network
9
RS-485 and Alarm
Interface
Connector for RS-485 devices. T+ and T- pins
connect to R+ and R- pins of PTZ receiver
respectively.
D+, D- pin connects to Ta, Tb pin of controller. For
cascading devices, the first DVR’s D+, D- pin should
be connected with the D+, D- pin of the next DVR.
Connector for alarm input.
Connector for alarm output.
10 Power Supply 100 to 240V AC power supply.
11 Power Switch Switch for turning on/off the device.
12 GND Ground
13 LINE IN BNC connector for audio input.
