HIKVISION DS-7316HUHI-K4 User Manual

Network Video Recorder User Manual
117
Before playing back by tag:
Add Tag Files
Go to Playback.
Search and play back the video file(s).
Click to add the tag.
Edit the tag information.
Click OK.
Max. 64 tags can be added to a single video file.
Edit Tag Files
Go to Playback.
Click Tag.
The available tags are white marked and displayed in the time bar.
Point the white marked tag in the time bar to access the tag information.
Edit Tag Files
Click to edit the tag name.
Click OK.
Play Tag Files
Go to Playback.
Click Custom Search on the left bottom to enter the Search Condition interface.
Enter the search conditions for the tag files, including the time and the tag keyword.

HIKVISION DS-7316HUHI-K4 Specifications

General

Bit rate	10000 Kbit/s
Internal	No
Product color	Black
Video streaming	Yes
Maximum frame rate	30 fps
Audio input channels	4.0 channels
Audio output channels	2.0 channels
Audio formats supported	G.711 μ-law
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.265, H.265+
Number of simultaneously playbacked channels	16 channels
Audio input	RCA
RS-232 ports	1
BNC input ports	16
Alarm output channels	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
Power consumption (typical)	65 W
Number of users	128 user(s)
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, SNMP
HDD interface	eSATA
Maximum HDD capacity	10000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
Weight	5000 g
