Network Video Recorder User Manual
119
Click Search.
On the search results interface, select an event video file/picture file and double click
to start playing the video.
Event Files
You can click or button to play 30s backward or forward.

Refer to Chapter 11 Event and Alarm Settings and Chapter 13 VCA Event Alarm for details
for event and alarm settings.

Refer to Chapter 7.7 Configure Event Triggered Recording for the event triggered
recording/capture settings.
Play by Sub-periods
Purpose:
The video files can be played in multiple sub-periods simultaneously on the screens.
Go to Playback.
Select icon at the left bottom corner to enter the sub-period playing mode.
Select a camera.

HIKVISION DS-7316HUHI-K4 Specifications

General

Bit rate	10000 Kbit/s
Internal	No
Product color	Black
Video streaming	Yes
Maximum frame rate	30 fps
Audio input channels	4.0 channels
Audio output channels	2.0 channels
Audio formats supported	G.711 μ-law
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.265, H.265+
Number of simultaneously playbacked channels	16 channels
Audio input	RCA
RS-232 ports	1
BNC input ports	16
Alarm output channels	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
Power consumption (typical)	65 W
Number of users	128 user(s)
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, SNMP
HDD interface	eSATA
Maximum HDD capacity	10000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
Weight	5000 g
