Network Video Recorder User Manual
53
If you have forgotten your pattern, you can select the Forgot My Pattern or Switch User
option to enter the normal login dialog box.
When the pattern you draw is different from the pattern you have configured, you should
try again.
If you have drawn the wrong pattern for more than 5 times, the system will switch to the
normal login mode automatically.
Log in via Password
Purpose:
If device has logged out, you must login the device before operating the menu and other functions.
Select the User Name in the dropdown list.
Login Interface
Input password.
Click OK to log in.
When you forget the password of the admin, you can click Forgot Password to reset the
password.
In the Login dialog box, if you enter the wrong password 7 times, the current user account
will be locked for 60 seconds.
Enter Wizard to Configure Quick Basic Settings
Purpose:
By default, the Setup Wizard starts once the device has loaded.
The Setup Wizard can walk you through some important settings of the device. If you don’t want
to use the Setup Wizard at that moment, click the Exit button.

Table of Contents

Other manuals for HIKVISION DS-7316HUHI-K4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7316HUHI-K4 and is the answer not in the manual?

HIKVISION DS-7316HUHI-K4 Specifications

General IconGeneral
Bit rate10000 Kbit/s
InternalNo
Product colorBlack
Video streamingYes
Maximum frame rate30 fps
Audio input channels4.0 channels
Audio output channels2.0 channels
Audio formats supportedG.711 μ-law
Maximum video resolution1920 x 1080 pixels
Video compression formatsH.264, H.265, H.265+
Number of simultaneously playbacked channels16 channels
Audio inputRCA
RS-232 ports1
BNC input ports16
Alarm output channels4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage100 - 240 V
Power consumption (typical)65 W
Number of users128 user(s)
Ethernet interface typeGigabit Ethernet
Supported network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, SNMP
HDD interfaceeSATA
Maximum HDD capacity10000 GB
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth390 mm
Width445 mm
Height70 mm
Weight5000 g
