Network Video Recorder User Manual
74
Configure Auto-Switch of Cameras
Purpose:
You can set the auto-switch of cameras to play in different display modes.
Go to System > Live View > General.
Set the video output interface, live view mode and dwell time.
Video Output Interface: Select the video output interface.
Live View Mode: Select the display mode for live view, e.g., 2*2, 1*5, etc.
Dwell Time: The time in seconds to dwell between switching of cameras when enabling auto-
switch. The range is from 5s to 300s.
Go to View to set the view layout.
Click OK to save the settings.
Configure Channel-zero Encoding
Purpose:
You can enable the channel-zero encoding when you need to get a remote view of many channels
in real time from web browser or CMS (Client Management System) software, in order to decrease
the bandwidth requirement without affecting the image quality.
Go to System > Live View > General.
Select the video output interface to Channel-Zero.
Go to System > Live View > Channel-Zero.
Check the checkbox to enable the channel-zero.
Live View- Channel-Zero Encoding
Configure the Frame Rate, Max. Bitrate Mode and Max. Bitrate. The higher frame
rate and bitrate settings result in the higher requirement of bandwidth.

Table of Contents

Other manuals for HIKVISION DS-7316HUHI-K4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7316HUHI-K4 and is the answer not in the manual?

HIKVISION DS-7316HUHI-K4 Specifications

General IconGeneral
Bit rate10000 Kbit/s
InternalNo
Product colorBlack
Video streamingYes
Maximum frame rate30 fps
Audio input channels4.0 channels
Audio output channels2.0 channels
Audio formats supportedG.711 μ-law
Maximum video resolution1920 x 1080 pixels
Video compression formatsH.264, H.265, H.265+
Number of simultaneously playbacked channels16 channels
Audio inputRCA
RS-232 ports1
BNC input ports16
Alarm output channels4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage100 - 240 V
Power consumption (typical)65 W
Number of users128 user(s)
Ethernet interface typeGigabit Ethernet
Supported network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, SNMP
HDD interfaceeSATA
Maximum HDD capacity10000 GB
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth390 mm
Width445 mm
Height70 mm
Weight5000 g
