Page #93 background imageLoading...
Page #93 background image
Network Video Recorder User Manual
92
Frame Rate (FPS - Frames Per Second): refers to how many frames are captured each second. A
higher frame rate is advantageous when there is movement in the video stream, as it maintains
image quality throughout.
Resolution: Image resolution is a measure of how much detail a digital image can hold: the
greater the resolution, the greater the level of detail. Resolution can be specified as the number
of pixel-columns (width) by the number of pixel-rows (height), e.g.,1024×768.
Bitrate: The bit rate (in kbit/s or Mbit/s) is often referred to as speed, but actually defines the
number of bits/time unit and not distance/time unit.
Enable H.264+ Mode: The H.264+ mode helps to ensure the high video quality with a lowered
bitrate. It can effectively reduce the need of bandwidth and HDD storage space.
A higher resolution, frame rate and bitrate setting will provide you the better video quality, but
it will also require more internet bandwidth and use more storage space on the hard disk drive.
Sub-Stream
The sub-stream is a second codec that runs alongside the mainstream. It allows you to reduce the
outgoing internet bandwidth without sacrificing your direct recording quality.
The sub-stream is often exclusively used by smartphone applications to view live video. Users with
limited internet speeds may benefit most from this setting.
The picture refers to the live picture capture in continuous or event recording type.
Picture Quality: set the picture quality to low, medium or high. The higher picture quality
results in more storage space requirement.
Interval: the interval of capturing live picture.
Configure Advanced Recording Settings
Go to Storage > Record Schedule.
Check Enable Schedule to enable scheduled recording.
Click Advanced to set the recording parameters.

Table of Contents

Other manuals for HIKVISION DS-7316HUHI-K4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7316HUHI-K4 and is the answer not in the manual?

HIKVISION DS-7316HUHI-K4 Specifications

General IconGeneral
Bit rate10000 Kbit/s
InternalNo
Product colorBlack
Video streamingYes
Maximum frame rate30 fps
Audio input channels4.0 channels
Audio output channels2.0 channels
Audio formats supportedG.711 μ-law
Maximum video resolution1920 x 1080 pixels
Video compression formatsH.264, H.265, H.265+
Number of simultaneously playbacked channels16 channels
Audio inputRCA
RS-232 ports1
BNC input ports16
Alarm output channels4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage100 - 240 V
Power consumption (typical)65 W
Number of users128 user(s)
Ethernet interface typeGigabit Ethernet
Supported network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, SNMP
HDD interfaceeSATA
Maximum HDD capacity10000 GB
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth390 mm
Width445 mm
Height70 mm
Weight5000 g
