HIKVISION DS-7316HUHI-K4 User Manual

Network Video Recorder User Manual
64
Click to enter the 5 MP Long Distance Transmission Settings interface.
5 MP Long Distance Transmission Settings
Select channel(s) to enable 5 MP Long Distance Transmission.
Click OK.
Click Apply to save the settings.
Enable the H.265 Stream Access
Purpose:
The device can automatically switch to the H.265 stream of IP camera (which supports H.265 video
format) for the initial access.
Click on the main menu bar.
Click Camera > IP Camera > More Settings > H.265 Auto Switch Configuration at the
top taskbar.
Check Enable H.265 (For Initial Access).
Click OK.
Upgrade the IP Camera
Purpose:
The IP camera can be remotely upgraded through the device.
Plug the U-flash drive with the IP camera’s firmware upgrade file to the device.

HIKVISION DS-7316HUHI-K4 Specifications

General

Bit rate	10000 Kbit/s
Internal	No
Product color	Black
Video streaming	Yes
Maximum frame rate	30 fps
Audio input channels	4.0 channels
Audio output channels	2.0 channels
Audio formats supported	G.711 μ-law
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.265, H.265+
Number of simultaneously playbacked channels	16 channels
Audio input	RCA
RS-232 ports	1
BNC input ports	16
Alarm output channels	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
Power consumption (typical)	65 W
Number of users	128 user(s)
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, SNMP
HDD interface	eSATA
Maximum HDD capacity	10000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
Weight	5000 g
