Network Video Recorder User Manual
151
Region Entrance Detection
Select a camera to configure.
Check Enable Region Entrance Detection checkbox.
Optionally, check Save VCA Picture checkbox to save the captured pictures of region
entrance detection.
Follow the steps to set the detection rules and detection areas.
1) Select an Arming Region to configure. Up to 4 regions are selectable.
2) Drag the sliders to set Sensitivity.
Sensitivity: The higher the value is, the more easily the detection alarm can be triggered.
Its range is [0-100].
3) Click Draw Region and draw a quadrilateral in the preview window by specifying four
vertexes of the detection region.
Set the arming schedule. Refer to Chapter 11.1 Configure Arming Schedule.
Set the linkage actions. Refer to Chapter 11.2 Configure Alarm Linkage Actions.
Click Apply.
Region Exiting Detection
Purpose:
Region exiting detection function detects objects that exit from a pre-defined virtual region.

Table of Contents

Other manuals for HIKVISION DS-7316HUHI-K4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7316HUHI-K4 and is the answer not in the manual?

HIKVISION DS-7316HUHI-K4 Specifications

General IconGeneral
Bit rate10000 Kbit/s
InternalNo
Product colorBlack
Video streamingYes
Maximum frame rate30 fps
Audio input channels4.0 channels
Audio output channels2.0 channels
Audio formats supportedG.711 μ-law
Maximum video resolution1920 x 1080 pixels
Video compression formatsH.264, H.265, H.265+
Number of simultaneously playbacked channels16 channels
Audio inputRCA
RS-232 ports1
BNC input ports16
Alarm output channels4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage100 - 240 V
Power consumption (typical)65 W
Number of users128 user(s)
Ethernet interface typeGigabit Ethernet
Supported network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, SNMP
HDD interfaceeSATA
Maximum HDD capacity10000 GB
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth390 mm
Width445 mm
Height70 mm
Weight5000 g
