HIKVISION DS-7316HUHI-K4 User Manual

Network Video Recorder User Manual
15
Set a Patrol .............................................................................................................. 79
Call a Patrol ............................................................................................................. 80
Set a Pattern ............................................................................................................ 81
Call a Pattern ........................................................................................................... 82
Set Linear Scan Limits .............................................................................................. 82
Call Linear Scan ....................................................................................................... 83
One-touch Park ....................................................................................................... 83
Auxiliary Functions ........................................................................................................... 84
Chapter 7 Storage ............................................................................................................................ 85
Storage Device Management ........................................................................................... 85
Install the HDD ........................................................................................................ 85
Add the Network Disk ............................................................................................. 85
Configure eSATA for Data Storage ........................................................................... 87
Storage Mode ................................................................................................................... 88
Configure HDD Group ............................................................................................. 88
Configure HDD Quota.............................................................................................. 90
Recording Parameters ...................................................................................................... 91
Main Stream ............................................................................................................ 91
Sub-Stream .............................................................................................................. 92
Picture ..................................................................................................................... 92
Configure Advanced Recording Settings ................................................................. 92
Configure Recording Schedule ......................................................................................... 93
Configure Continuous Recording ..................................................................................... 95
Configure Motion Detection Triggered Recording ........................................................... 95
Configure Event Triggered Recording ............................................................................... 96
Configure Alarm Triggered Recording .............................................................................. 96
Configure Picture Capture ................................................................................................ 96
Configure Holiday Recording and Capture ..................................................................... 97
Configure Redundant Recording and Capture ............................................................... 99
Configure 1080p Lite .................................................................................................... 100
Enable the 1080P Lite Mode ............................................................................... 100
Disable the 1080P Lite Mode .............................................................................. 101
Chapter 8 Disk Array .................................................................................................................... 102
Create Disk Array ............................................................................................................ 102
Enable RAID ........................................................................................................... 102

HIKVISION DS-7316HUHI-K4 Specifications

General

Bit rate	10000 Kbit/s
Internal	No
Product color	Black
Video streaming	Yes
Maximum frame rate	30 fps
Audio input channels	4.0 channels
Audio output channels	2.0 channels
Audio formats supported	G.711 μ-law
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.265, H.265+
Number of simultaneously playbacked channels	16 channels
Audio input	RCA
RS-232 ports	1
BNC input ports	16
Alarm output channels	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
Power consumption (typical)	65 W
Number of users	128 user(s)
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, SNMP
HDD interface	eSATA
Maximum HDD capacity	10000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
Weight	5000 g
