HIKVISION DS-7316HUHI-K4 User Manual

Network Video Recorder User Manual
14
System Operation ............................................................................................................. 58
Log out..................................................................................................................... 58
Shut Down the Device ............................................................................................. 58
Reboot the Device ................................................................................................... 58
Chapter 3 Camera Management ................................................................................................... 60
Add the IP Cameras .......................................................................................................... 60
Add the IP Camera Manually .................................................................................. 60
Add the Automatically Searched Online IP Cameras .............................................. 61
Connecting PoC Cameras ........................................................................................ 61
Configure Signal Input Channel ............................................................................... 62
Configuring 5 MP Long Distance Transmission ....................................................... 63
Enable the H.265 Stream Access ...................................................................................... 64
Upgrade the IP Camera .................................................................................................... 64
Chapter 4 Camera Settings ............................................................................................................ 66
Configure OSD Settings ................................................................................................... 66
Configure Privacy Mask .................................................................................................... 67
Configure the Video Parameters ...................................................................................... 68
Configure the Day/Night Switch ....................................................................................... 68
Configure Other Camera Parameters ............................................................................... 69
Chapter 5 Live View ....................................................................................................................... 70
Start Live View .................................................................................................................. 70
Digital Zoom ............................................................................................................ 70
Live View Strategy ................................................................................................... 71
Target Detection ............................................................................................................... 71
Configure Live View Settings ............................................................................................ 72
Configure Live View Layout .............................................................................................. 72
Configure Auto-Switch of Cameras .................................................................................. 74
Configure Channel-zero Encoding .................................................................................... 74
Using an Auxiliary Monitor............................................................................................... 75
Chapter 6 PTZ Control ................................................................................................................... 76
PTZ Control Wizard ........................................................................................................... 76
Configure PTZ Parameters ................................................................................................ 76
Set PTZ Presets, Patrols & Patterns .................................................................................. 77
Set a Preset ............................................................................................................. 77
Call a Preset ............................................................................................................. 78

HIKVISION DS-7316HUHI-K4 Specifications

General

Bit rate	10000 Kbit/s
Internal	No
Product color	Black
Video streaming	Yes
Maximum frame rate	30 fps
Audio input channels	4.0 channels
Audio output channels	2.0 channels
Audio formats supported	G.711 μ-law
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.265, H.265+
Number of simultaneously playbacked channels	16 channels
Audio input	RCA
RS-232 ports	1
BNC input ports	16
Alarm output channels	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
Power consumption (typical)	65 W
Number of users	128 user(s)
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, SNMP
HDD interface	eSATA
Maximum HDD capacity	10000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
Weight	5000 g
