HIKVISION DS-7316HUHI-K4 User Manual

Network Video Recorder User Manual
35
 Batteries are fresh and not out of charge.
 IR receiver is not obstructed.
 No fluorescent lamp is used nearby
If the remote still can’t function properly, please change a remote and try again, or contact the
device provider.
USB Mouse Operation
A regular 3-button (Left/Right/Scroll-wheel) USB mouse can also be used with this device. To use a
USB mouse:
Plug USB mouse into one of the USB interfaces on the front panel of the device.
The mouse should automatically be detected. If in a rare case that the mouse is not
detected, the possible reason may be that the two devices are not compatible, please refer to
the recommended the device list from your provider.
The operation of the mouse:
Description of the Mouse Control
Name
Action
Description
Left-Click
Single-Click

Live view: Select channel and show the quick set
menu.

Menu: Select and enter.
Double-Click
Live view: Switch between single-screen and multi-
screen.
Click and Drag

PTZ control: pan, tilt and zoom.

Video tampering, privacy mask and motion
detection: Select target area.

Digital zoom-in: Drag and select target area.

Live view: Drag channel/time bar.
Right-Click
Single-Click

Live view: Show menu.

Menu: Exit current menu to upper level menu.
Scroll-Wheel
Scrolling up

Live view: Previous screen.

Menu: Previous item.
Scrolling
down

Live view: Next screen.

Menu: Next item.

HIKVISION DS-7316HUHI-K4 Specifications

General

Bit rate	10000 Kbit/s
Internal	No
Product color	Black
Video streaming	Yes
Maximum frame rate	30 fps
Audio input channels	4.0 channels
Audio output channels	2.0 channels
Audio formats supported	G.711 μ-law
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.265, H.265+
Number of simultaneously playbacked channels	16 channels
Audio input	RCA
RS-232 ports	1
BNC input ports	16
Alarm output channels	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	100 - 240 V
Power consumption (typical)	65 W
Number of users	128 user(s)
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, SNMP
HDD interface	eSATA
Maximum HDD capacity	10000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
Weight	5000 g
