HIKVISION DS-7732NI-I4 Quick Start Guide

Network Video Recorder Quick Start Guide
10
No.
Name
Function Description
Turns on/off PTZ light (if applicable) in PTZ
control mode.
Switches between play and reverse play in
playback mode.
F2/ AUX
Cycles through tab pages.
Switches between channels in synchronous
playback mode.
MENU/WIPER
Returns to the Main menu (after successful
login).
Presses and holds the button for five seconds to
turn off audible key beep.
Starts wiper (if applicable) in PTZ control mode.
Shows/hides the control interface in playback
mode.
PREV/FOCUS-
Switches between single screen and
multi-screen mode.
Adjusts the focus in conjunction with the
A/FOCUS+ button in PTZ control mode.
PTZ/IRIS-
Enters the PTZ Control mode.
Adjusts the iris of the PTZ camera in PTZ control
mode.
8
Control
Buttons
DIRECTION
Navigates between different fields and items in
menus.
In the playback mode, use the Up and Down
buttons to speed up and slow down recorded
video. Use the Left and Right buttons to select
the next and previous video files.
Cycles through channels in live view mode.
Controls the movement of the PTZ camera in
PTZ control mode.
ENTER
Confirms selection in any of the menu modes.
Checks the checkbox fields.

HIKVISION DS-7732NI-I4 Specifications

General

Playback modes	Pause, Play
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Video input channels	32 channels
Alarm output channels	4
Video formats supported	H.264, H.265, MPEG4
Resolution at capture speed	1920x1080@60fps, 3840x2160@30fps
On/off switch	Yes
Product color	Black, Silver
Rack capacity	1.5U
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	20 W
RS-485 ports	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
HDD capacity	- GB
HDD interface	Serial ATA
Maximum storage capacity	24 TB
Number of HDDs installed	-
Total installed storage capacity	12000 GB

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
