Network Video Recorder Quick Start Guide
28
Connect at least 4 dots to draw the pattern.
Each dot can be connected for once only.
Step 3 Draw the same pattern again to confirm it. When the two patterns match, the pattern is
configured successfully.
If the two patterns are different, you must set the pattern again.
3.4 Login to the System
Purpose:
If the device has logged out, you must log in the device before operating the menu and other
functions. You can select to log in by unlock pattern or passwrod input either.
Step 1 Right click the mouse on the screen and select the menu to enter the interface.
Step 2 Select the User Name in the dropdown list.
Figure 3-3 Login Interface
Step 3 Input Password.
Step 4 Click Login to log in.
In the Login dialog box, if you enter the wrong password 7 times, the current user account will be
locked for 60 seconds.

Other manuals for HIKVISION DS-7732NI-I4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7732NI-I4 and is the answer not in the manual?

HIKVISION DS-7732NI-I4 Specifications

General IconGeneral
Playback modesPause, Play
Maximum resolution3840 x 2160 pixels
Alarm input channels16
Video input channels32 channels
Alarm output channels4
Video formats supportedH.264, H.265, MPEG4
Resolution at capture speed1920x1080@60fps, 3840x2160@30fps
On/off switchYes
Product colorBlack, Silver
Rack capacity1.5U
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
AC input voltage100 - 240 V
Power consumption (typical)20 W
RS-485 ports1
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100 Mbit/s
HDD capacity- GB
HDD interfaceSerial ATA
Maximum storage capacity24 TB
Number of HDDs installed-
Total installed storage capacity12000 GB
Weight and Dimensions IconWeight and Dimensions
Depth390 mm
Width445 mm
Height70 mm
