Network Video Recorder User Manual
183
Please refer to the Chapter 9.4 Intrusion Detection for operating steps to configure the
unattended baggage detection.
The Threshold[5s-20s] in the Rule Settings defines the time of the objects left over in the
region. If you set the value as 10, alarm is triggered after the object is left and stay in the
region for 10s. And the Sensitivity defines the similarity degree of the background image.
Usually, when the sensitivity is high, a very small object left in the region can trigger the
alarm.
Up to 4 rules can be configured.
10.8 Object Removal Detection
Purpose:
Object removal detection function detects the objects removed from the pre-defined region, such
as the exhibits on display, and a series of actions can be taken when the alarm is triggered.
Please refer to the Chapter 9.4 Intrusion Detection for operating steps to configure the
object removal detection.
The Threshold [5s-20s] in the Rule Settings defines the time of the objects removed from
the region. If you set the value as 10, alarm is triggered after the object disappears from
the region for 10s. And the Sensitivity defines the similarity degree of the background
image. Usually, when the sensitivity is high, a very small object taken from the region can
trigger the alarm.
Up to 4 rules can be configured.
10.9 Audio Exception Detection
Purpose:
Audio exception detection function detects the abnormal sounds in the surveillance scene, such as
the sudden increase / decrease of the sound intensity, and some certain actions can be taken when
the alarm is triggered.
Step 1 Enter the VCA settings interface.
Menu> Camera> VCA
Step 2 Select the camera to configure the VCA.
You can click the checkbox of Save VCA Picture to save the captured pictures of VCA
detection.

Table of Contents

Other manuals for HIKVISION DS-9664NI-I8

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-9664NI-I8 and is the answer not in the manual?

HIKVISION DS-9664NI-I8 Specifications

General IconGeneral
Product colorBlack
Rack capacity2U
Rack mountingYes
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)30 W
Display modesLive view
Input bandwidth320 Mbit/s
Output bandwidth256 Mbit/s
Maximum frame rate60 fps
Maximum resolution3840 x 2160 pixels
Alarm input channels16
Video input channels64 channels
Alarm output channels4
Supported resolutions3840 x 2160, 3840 x 2160, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video recording modes1080p, 2160p
Video formats supportedH.264, H.265, MPEG4
Still image resolution(s)3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100, 1000 Mbit/s
Supported network protocolsTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
RAID levels0, 1, 5, 6, 10
HDD capacity0 GB
HDD interfaceSerial ATA
Maximum storage capacity48 TB
Number of HDDs installed0
Number of HDDs supported8
Wi-FiNo
Weight and Dimensions IconWeight and Dimensions
Depth445 mm
Width470 mm
Height90 mm
Weight10000 g
