HIKVISION DS-9664NI-I8 User Manual

Network Video Recorder User Manual
216
Chapter 13 RAID
This chapter is applicable for DS-9600NI-I8 and DS-9600NI-I16 series NVR.
13.1 Configuring Array
Purpose:
RAID (redundant array of independent disks) is a storage technology that combines multiple disk
drive components into a logical unit. A RAID setup stores data over multiple hard disk drives to
provide enough redundancy so that data can be recovered if one disk fails. Data is distributed
across the drives in one of several ways called "RAID levels", depending on what level of
redundancy and performance is required.
The NVR supports the disk array that is realized by software. You can enable the RAID function on
your demand.
The DS-9600NI-I8 and DS-9600NI-I16 series NVR support the RAID0, RAID1, RAID5, RAID6 and RAID
10 array types.
Before you start:
Please install the HDD(s) properly and it is recommended to use the same enterprise-level HDDs
(including model and capacity) for array creation and configuration so as to maintain reliable and
stable running of the disks.
Introduction:
The NVR can store the data (such as record, picture, log information) in the HDD only after you
have created the array or you have configured network HDD (refer to Chapter14.2 Managing
Network HDD). Our device provides two ways for creating array, including one-touch configuration
and manual configuration. The following flow chart shows the process of creating array.

HIKVISION DS-9664NI-I8 Specifications

General

Product color	Black
Rack capacity	2U
Rack mounting	Yes
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	30 W
Display modes	Live view
Input bandwidth	320 Mbit/s
Output bandwidth	256 Mbit/s
Maximum frame rate	60 fps
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Video input channels	64 channels
Alarm output channels	4
Supported resolutions	3840 x 2160, 3840 x 2160, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video recording modes	1080p, 2160p
Video formats supported	H.264, H.265, MPEG4
Still image resolution(s)	3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
RAID levels	0, 1, 5, 6, 10
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	48 TB
Number of HDDs installed	0
Number of HDDs supported	8
Wi-Fi	No

Weight and Dimensions

Depth	445 mm
Width	470 mm
Height	90 mm
Weight	10000 g
