Network Video Recorder User Manual
43
Step 3 Click the Yes button.
OPTION 2: By operating the front panel
Step 1 Press and hold the POWER button on the front panel for 3 seconds.
Step 2 Enter the administrator’s username and password in the dialog box for authentication.
Step 3 Click the Yes button.
Do not press the POWER button again when the system is shutting down.
Rebooting the NVR
In the Shutdown menu, you can also reboot the NVR.
Step 1 Enter the Shutdown menu by clicking Menu > Shutdown.
Step 2 Click the Logout button to lock the NVR or the Reboot button to reboot the NVR.
2.1.2 Activating Your Device
Purpose:
For the first-time access, you need to activate the device by setting an admin password. No
operation is allowed before activation. You can also activate the device via Web Browser, SADP or
Client Software.
Step 1 Input the same password in the text field of Create New Password and Confirm New
Password.
Figure 2-2 Settings Admin Password

Table of Contents

Other manuals for HIKVISION DS-9664NI-I8

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-9664NI-I8 and is the answer not in the manual?

HIKVISION DS-9664NI-I8 Specifications

General IconGeneral
Product colorBlack
Rack capacity2U
Rack mountingYes
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)30 W
Display modesLive view
Input bandwidth320 Mbit/s
Output bandwidth256 Mbit/s
Maximum frame rate60 fps
Maximum resolution3840 x 2160 pixels
Alarm input channels16
Video input channels64 channels
Alarm output channels4
Supported resolutions3840 x 2160, 3840 x 2160, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video recording modes1080p, 2160p
Video formats supportedH.264, H.265, MPEG4
Still image resolution(s)3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100, 1000 Mbit/s
Supported network protocolsTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
RAID levels0, 1, 5, 6, 10
HDD capacity0 GB
HDD interfaceSerial ATA
Maximum storage capacity48 TB
Number of HDDs installed0
Number of HDDs supported8
Wi-FiNo
Weight and Dimensions IconWeight and Dimensions
Depth445 mm
Width470 mm
Height90 mm
Weight10000 g
