Network Video Recorder User Manual
97
5.2 Configuring Recording and Capture Schedule
Purpose:
Set the record schedule, and then the camera automatically starts/stops recording according to the
configured schedule.
In this chapter, we take the record schedule procedure as an example, and the same procedure can
be applied to configure schedule for both recording and capture. To schedule the automatic
capture, you need to choose the Capture tab in the Schedule interface.
Step 1 Enter the Record Schedule interface.
Menu>Record/Capture>Schedule
Step 2 Configure Record Schedule
1) Select Record/Capture Schedule.
Figure 5-7 Record Schedule
Different recording types are marked in different color icons.
Continuous: scheduled recording.
Event: recording triggered by all event triggered alarm.
Motion: recording triggered by motion detection.
Alarm: recording triggered by alarm.
M/A: recording triggered by either motion detection or alarm.
To Next Page
