Table 1-1 Panel Description
No.
Name
Function Description
1
Status
Indicators
ALARM
Turns red when a sensor alarm is detected.
READY
Turns blue when the device is functioning
properly.
STATUS
Turns blue when device is controlled by an IR
remote.
Turns red when controlled by a keyboard and
purple when IR remote and keyboard is used at
the same time.
HDD
Flickers red when data is being read from or
written to HDD.
MODEM
Reserved for future usage.
Tx/Rx
Flickers blue when network connection is
functioning properly.
GUARD
Turns blue when the device is in armed status;
at this time, an alarm is enabled when an event
is detected.
Turns off when the device is unarmed. The
arm/disarm status can be changed by pressing
and holding on the ESC button for more than 3
seconds in live view mode.
2
IR Receiver
Receiver for IR remote control.
3
Front Panel Lock
Locks or unlocks the panel by the key.
4
DVD-R/W
Slot for DVD-R/W disk.
5
Alphanumeric Buttons
Switches to the corresponding channel in live
view or PTZ control mode.
Inputs numbers and characters in edit mode.
Switches between different channels in
playback mode.
Turns blue when the corresponding channel is
recording; turns red when the channel is in
network transmission status; turns pink when
the channel is recording and transmitting.

HIKVISION DS-9664NI-I8 Specifications

General

Product color	Black
Rack capacity	2U
Rack mounting	Yes
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	30 W
Display modes	Live view
Input bandwidth	320 Mbit/s
Output bandwidth	256 Mbit/s
Maximum frame rate	60 fps
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Video input channels	64 channels
Alarm output channels	4
Supported resolutions	3840 x 2160, 3840 x 2160, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video recording modes	1080p, 2160p
Video formats supported	H.264, H.265, MPEG4
Still image resolution(s)	3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720, 1024 x 768
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
RAID levels	0, 1, 5, 6, 10
HDD capacity	0 GB
HDD interface	Serial ATA
Maximum storage capacity	48 TB
Number of HDDs installed	0
Number of HDDs supported	8
Wi-Fi	No

Weight and Dimensions

Depth	445 mm
Width	470 mm
Height	90 mm
Weight	10000 g
