HIKVISION DS-9664NI-M8 User Manual

Network Video Recorder User Manual
xii
Contents
Chapter 1 Basic Operation .............................................................................................................. 1
1.1 Activate Your Device ......................................................................................................... 1
1.1.1 Default User and IP Address ................................................................................... 1
1.1.2 Activate via Local Menu ......................................................................................... 1
1.1.3 Activate via SADP ................................................................................................... 2
1.1.4 Activate via Client Software ................................................................................... 3
1.1.5 Activate via Web Browser ...................................................................................... 6
1.2 Configure TCP/IP ............................................................................................................... 7
1.3 Configure HDD .................................................................................................................. 9
1.4 Add Network Camera ....................................................................................................... 9
1.4.1 Add Automatically Searched Online Network Camera ......................................... 10
1.4.2 Add Network Camera Manually ........................................................................... 10
1.4.3 Add Network Camera Through PoE ...................................................................... 11
1.4.4 Add Solar-Powered Camera Through OTAP Protocol ........................................... 14
1.4.5 Add Network Camera via Customized Protocol ................................................... 15
1.5 Connect to Platform ........................................................................................................ 16
1.5.1 Configure ISUP ..................................................................................................... 16
1.5.2 Configure Hik-Connect ......................................................................................... 18
1.5.3 Configure OTAP .................................................................................................... 19
Chapter 2 Camera Settings ........................................................................................................... 21
2.1 Configure OSD ................................................................................................................. 21
2.2 Configure Image Parameters .......................................................................................... 22
2.3 Configure Privacy Mask .................................................................................................. 22
2.4 Configure IP Camera Time Sync ...................................................................................... 23
2.5 Configure Camera Microphone Settings ......................................................................... 24
2.6 Configure Solar-Powered Camera Parameters................................................................ 25
2.7 Import Network Camera Certificate................................................................................ 25
2.8 Import/Export IP Camera Configuration Files ................................................................. 25
2.9 Save Camera VCA Data ................................................................................................... 26

HIKVISION DS-9664NI-M8 Specifications

General

Video codecs	H.265+/H.265/H.264+/H.264
Input bandwidth	400 Mbit/s
Maximum resolution	7680 x 4320 pixels
Alarm input channels	16
Video input channels	64 channels
Alarm output channels	9
Supported resolutions	8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Number of simultaneously playbacked channels	16 channels
Certification	CE, FCC Part 15 Subpart B, ANSI C63.4-2014 EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
Product color	Black
Rack capacity	2U
Rack mounting	Yes
Brand compatibility	Hikvision Digital Technology
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	50 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	-
RAID levels	0, 1, 5, 6, 10
HDD capacity	- GB
HDD interface	SATA, eSATA
Maximum storage capacity	14 TB
eSATA ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Supported network protocols	TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Internal SATA ports quantity	8

Weight and Dimensions

Depth	465 mm
Width	445 mm
Height	93 mm
Weight	10000 g
