HIKVISION DS-9664NI-M8 User Manual

Network Video Recorder User Manual
178
video?
Solution
Check if the encoding type at live view toolbar is H.265.
17.2.6 Why is the timeline at playback not constant?
Reason
1. When the video recorder is using event recording, it only records video when event occurs.
Hence the video may not be continuous.
2. Exception occurs, such as the device offline, HDD error, record exception, network camera
offline, etc.
Solution
1. Ensure the recording type is continuous recording.
2. Go to Maintenance → Log Information. Search the log file during the video time period. See if
there are unexpected events, such as HDD error, record exception, etc.
17.2.7 Why is the video recorder notifying the network is unreachable
when a network camera is being added?
Reason
1. The IP address or port of network camera is incorrect.
2. The network between video recorder and camera is disconnected.
Solution
1. Go to Camera → Camera → IP Camera. Click of the selected camera, and edit its IP
address and port. Ensure the video recorder and camera is using the same port.
2. Go to Maintenance → Network → Detection. Enter the IP address of network camera in
Destination Address, and click Test to see if the network is reachable.
17.2.8 Why is the IP address of network camera being changed
automatically?
Reason
When network camera and video recorder are using the same switch but in different subnets, the
video recorder will change the IP address of network camera to the same subnet as itself.

HIKVISION DS-9664NI-M8 Specifications

General

Video codecs	H.265+/H.265/H.264+/H.264
Input bandwidth	400 Mbit/s
Maximum resolution	7680 x 4320 pixels
Alarm input channels	16
Video input channels	64 channels
Alarm output channels	9
Supported resolutions	8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Number of simultaneously playbacked channels	16 channels
Certification	CE, FCC Part 15 Subpart B, ANSI C63.4-2014 EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
Product color	Black
Rack capacity	2U
Rack mounting	Yes
Brand compatibility	Hikvision Digital Technology
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	50 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	-
RAID levels	0, 1, 5, 6, 10
HDD capacity	- GB
HDD interface	SATA, eSATA
Maximum storage capacity	14 TB
eSATA ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Supported network protocols	TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Internal SATA ports quantity	8

Weight and Dimensions

Depth	465 mm
Width	445 mm
Height	93 mm
Weight	10000 g
