Network Video Recorder User Manual
58
Chapter 6 Event
6.1 Normal Event Alarm
6.1.1 Configure Motion Detection Alarms
Motion detection enables the device to detect the moving objects in the monitored area and
trigger alarms.
Steps
1. Go to System → Event → Normal Event → Motion Detection.
2. Select a camera.
3. Check Enable.
4. Set the motion detection rule.
For cameras have
human and vehicle
detection function.
Click Draw Area to draw the detection area(s) on the preview screen.
Set Detection Target as Human or Vehicle to discard alarms which
are not triggered by human body or vehicle.
For cameras do not
have human and
vehicle detection
function.
Click Full screen to set the full-screen as the detection area, or drag
on the preview screen to draw the customized detection area.
5. Set Sensitivity
Sensitivity
Sensitivity ranges from 0 to 100. It allows you to calibrate how readily movement triggers the
alarm. A higher value results in the more readily to triggers motion detection.
6. Set the arming schedule. Refer to Configure Arming Schedule.
7. Set linkage actions. Refer to Configure Linkage Actions.
6.1.2 Configure Video Loss Alarms
Video loss detection detects video loss of a channel and takes alarm response action(s).
Steps
1. Go to System → Event → Normal Event → Video Loss.
2. Select a camera.
3. Check Enable.
4. Set the arming schedule. Refer to Configure Arming Schedule.

HIKVISION DS-9664NI-M8 Specifications

General

Video codecs	H.265+/H.265/H.264+/H.264
Input bandwidth	400 Mbit/s
Maximum resolution	7680 x 4320 pixels
Alarm input channels	16
Video input channels	64 channels
Alarm output channels	9
Supported resolutions	8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Number of simultaneously playbacked channels	16 channels
Certification	CE, FCC Part 15 Subpart B, ANSI C63.4-2014 EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
Product color	Black
Rack capacity	2U
Rack mounting	Yes
Brand compatibility	Hikvision Digital Technology
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	50 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	-
RAID levels	0, 1, 5, 6, 10
HDD capacity	- GB
HDD interface	SATA, eSATA
Maximum storage capacity	14 TB
eSATA ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Supported network protocols	TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Internal SATA ports quantity	8

Weight and Dimensions

Depth	465 mm
Width	445 mm
Height	93 mm
Weight	10000 g
