Network Video Recorder User Manual
173
16.12.4 RTSP Digest Algorithm
RTSP digest algorithm is based on RTSP protocol, it is an algorithm for digest authentication of the
user authentication. You can configure RTSP digest algorithm via web browser.
Go to Configuration → System → Security → Authentication via web browser to select the
required RTSP digest algorithm type.
16.12.5 ISAPI Service
ISAPI (Internet Server Application Programming Interface) is an open protocol based on HTTP,
which can realize the communication between the system devices (e.g., network camera, NVR,
etc.). The device is as a server, the system can find and connect the device.
Steps
1. Go to System → System Service → System Service.
2. Check Enable ISAPI.
3. Click Apply.
4. Restart the device to take effect the settings.
16.12.6 HTTP Authentication
If you need to enable the HTTP service, you can set HTTP authentication to enhance access
security.
Steps
1. Go to Maintenance → System Service → System Service.
Figure 16-23 HTTP Authentication
2. Check Enable HTTP.
3. Select HTTP Authentication Type.
Note
Two authentication types are selectable, for security reasons, it is recommended to select
digest as the authentication type.
4. Click Apply to save the settings.
5. Restart the device to take effect the settings.
16.12.7 HTTP/Web Digest Algorithm
HTTP/Web digest algorithm is based on HTTP protocol, it is an algorithm for digest authentication

HIKVISION DS-9664NI-M8 Specifications

General

Video codecs	H.265+/H.265/H.264+/H.264
Input bandwidth	400 Mbit/s
Maximum resolution	7680 x 4320 pixels
Alarm input channels	16
Video input channels	64 channels
Alarm output channels	9
Supported resolutions	8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Number of simultaneously playbacked channels	16 channels
Certification	CE, FCC Part 15 Subpart B, ANSI C63.4-2014 EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
Product color	Black
Rack capacity	2U
Rack mounting	Yes
Brand compatibility	Hikvision Digital Technology
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	50 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi	-
RAID levels	0, 1, 5, 6, 10
HDD capacity	- GB
HDD interface	SATA, eSATA
Maximum storage capacity	14 TB
eSATA ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Supported network protocols	TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Internal SATA ports quantity	8

Weight and Dimensions

Depth	465 mm
Width	445 mm
Height	93 mm
Weight	10000 g
