HIKVISION DS-KD-KK

Table 2-8 Descripon
No. Descripon No. Descripon
1 Screen 5 Back Buon
2 Up Buon 6
Module-
connecng
Interface
(output)
3 Down Buon 7
Module-
connecng
Interface (input)
4 Conrm Buon 8 Debug Port
Informaon Module
Figure 2-9 Informaon Module
Table 2-9 Descripon
No. Descripon
1 Display Area
2
Module-connecng
Interface (output)
3
Module-connecng
Interface (input)
4 Debugging Port
Touch-Display Module
Figure 2-10 Touch-Display Module
6
