HIKVISION DS-KD-KK User Manual

Before You Start
Figure 4-31 Mounng Frame
Note
●
It takes two three-module mounng frames. The dimension of
three-module mounng frame (W × H × D) is: 321 mm × 107
mm × 33 mm.
●
The dimensions above are for reference only. The actual size
can be slightly
dierent from the theorecal dimension.
Steps
1. Paste two Scker 1 onto the wall. Make sure the sckers are
placed horizontally via measuring with the gradienter.
2. Drill 8 holes according to the screw holes on the scker.
Note
●
The suggested size of hole is 6 (diameter) × 25 (depth) mm.
●
The suggested length of cables le outside is 270 mm.
3. Pull out the cable through the cable hole of the le scker.
Figure 4-32 Drill Screw Holes
4.
Remove the sckers and insert the expansion sleeves into the
screw holes.
5. Thread the
module-connecng line (400 mm) and grounding
line across the thread hole of both frames.
26

HIKVISION DS-KD-KK Specifications

General

Product color	Black, Grey, White
Brand compatibility	Hikvision
International Protection (IP) code	IP65
Package weight	438 g
Quantity per pack	1 pc(s)
Storage temperature (T-T)	10 - 95 °C
Operating temperature (T-T)	-40 - 55 °C
Sustainability certificates	RoHS, WEEE, REACH
DC input voltage	12 V

Weight and Dimensions

Depth	33.7 mm
Width	98.2 mm
Height	100.2 mm
Weight	190 g
