HIKVISION DS-KD8003-IME1 - Keypad Module; Indicator Module

Video Intercom Module Door Station·Quick Start Guide
3
1.3 Keypad Module
Figure 1-3 Keypad Module Appearance
Table 1-3 Appearance Description
No.
Description
1
Button
2
Module-connecting Interface(output)
3
Module-connecting Interface(input)
4
Debug Port
1.4 Indicator Module
Figure 1-4 Keypad Module Appearance
