HIKVISION DS-KD8003-IME1 - Appearance; Main Unit

Video Intercom Module Door Station·Quick Start Guide
1
1 Appearance
1.1 Main Unit
Figure 1-1 Main Unit Appearance
Table 1-1 Appearance Description
No.
Description
1
Microphone
2
Low Illumination IR Supplement Light
3
Built-in Camera
4
Loudspeaker
5
Call Button
6
Nametag
7
TAMPER
8
Network Interface
9
Module-connecting Interface(output)
10
Terminals
Nametag area supports insert customized name card.
The suggested card size is: 58 (L) x 11.7(W) mm.
