HIKVISION DS-KD8102

Video Intercom Door Station·User Manual
6
3 Typical Application
Network Cable
Optical Fiber
One Resident
RS-485
Wi-Fi
PC Client
Center Master Station
Door Station
IPC
Master Station
In Guard's Room
Outer Door Station
Video/Audio
Distributor
Card
Reader
Card
Reader
1F
Resident 1
2F
3F
4F
Video/Audio
Distributor
LAN
Resident 2
Resident 1Resident 2
Resident 1Resident 2
Resident 1Resident 2
Indoor
Extension 2
Indoor
Extension 2
Building
App
Figure 3-1 Typical Application of Door Station
