HIKVISION DS-KD8102

Video Intercom Door Station·User Manual
31
Figure 7-5 Local Parameters Settings Interface (Door Station)
Figure 7-6 Local Parameters Settings Interface (Outer Door Station)
2. Edit local parameters.
1) Move the cursor to parameters to be configured.
2) Press the # key to enter or exit the editing mode.
3. Press the * key to exit the network configuration interface after accomplishing local
parameters settings.
 In the main/sub door station mode, the serial No. of main door station should be set
as 0, and the serial No. of sub door station should be larger than 0.
 For each main door station, at most 8 sub door stations can be installed.
 For the outer door station, the serial No. cannot be set as 0.
7.3.2 Editing Network Parameters
Purpose:
Network connection is mandatory for the use of door station.
Steps:
1. Enter the network parameters settings interface.
1) Press the number keys 4 and 6 to switch to the network configuration interface
