HIKVISION DS-KD8102 User Manual

Video Intercom Door Station·User Manual
26
Screw
Screw
Figure 5-13 Insert the Gang Box into the Wall
3. Make sure the edges of the gang box align to the wall.
4. Route the cables of the door station through the cable hole.
5. Put the door station into the gang box.
Figure 5-14 Install the Door Station
6. Fix the door station to the gang box with 4 crews.

HIKVISION DS-KD8102 Specifications

General

Brand	HIKVISION
Model	DS-KD8102
Category	Intercom System
Language	English
