Chapter 1 Applicaon Mode Conguraon
Note
●
The supported applicaon modes vary with dierent models. The actual device prevails.
●
If the applicaon mode supports area drawing, you can check Display All Areas to display all the
lines and areas, convenient to view the eect of all the lines and areas. If you uncheck it, only
the current selected lane will be displayed, convenient to draw the current lane.
Cauon
You can click Default to restore all the set parameters to the default sengs. Please operate with
care.
1.1 Set Checkpoint Capture
1.1.1 Set Checkpoint Single I/O
Set checkpoint single I/O if capture is triggered by external I/O signal (digital signal). In this mode,
the
informaon including the vehicle passing me, vehicle overview, license plate number, license
plate color, vehicle color, the facial features of the driver and the front passenger, etc. will be
recorded.
Before You Start
Connect F+ of the I/O signal to the T interface of the device, and F- to the GND of the device.
Steps
1.
Go to
Conguraon → Capture → Applicaon Mode .
2.
Select Applicaon Mode as Checkpoint Single I/O.
