The eecve status should stay dierent with the default status for I/O to take eect. And
the default status changes according to the selecon of the eecve status. If you set the
eecve status as high level, the default level goes to low level.
Pulse
When pulse signal is output to the supplement light, the light will
ash.
If you set the eecve status as pulse, you can select the default status as high level or low
level, and set Frequency
Coecient which is the frequency mulplicaon of 25 of output
pulse by ash light, to keep the ash light as constant. You can set it as default value.
Light Compensaon Mode
Select Checkpoint to enable checkpoint capture light supplement. Select Violaon Acon to
enable
violaon capture light supplement.
Duty Rao
It is the me occupaon of the high level in a certain period. The higher the duty rao, the
brighter the solid light. High duty rao will cut life span of the solid light.
3.
Set the supplement light control mode.
-
Check Default to disable the supplement light.
-
Check Time Schedule when you want the supplement light to be enabled during a xed me
period. Set the start me and end me.
-
Check Environment Brightness when you want the supplement light to be controlled by
detecng the surroundings brightness automacally. Set the brightness threshold. The higher
the threshold is, the harder the supplement light can be enabled.
-
Check License Plate Brightness when you want the supplement light to be enabled according
to the license plate brightness automacally. It is valid only when you select Eecve Status
as Pulse.
Note
The four modes conict with each other. You can only enable one mode.
4.
Oponal: Select other I/O(s) to copy the same sengs.
5.
Click Save.
1.6.4 Set Picture
Composion
You can enable the picture composion to composite several pictures into one to make it
convenient to view the
violaon captured pictures.
Steps
Note
Funcons and parameters vary with dierent models. The actual device prevails.
