4.11 Brake Detection Switch
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 38 CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4)
4.11 Brake Detection Switch
Tools required: Small screwdriver
13 mm socket
Ratchet
Extension
Removal
1. Set the brakes.
2. Raise the bed to the highest position.
3. Raise the right, foot end siderail to the up and locked position.
SHOCK HAZARD:
Unplug the bed from its power source. Failure to do so could cause
personal injury or equipment damage.
4. Unplug the bed from its power source. Let the bed sit for 60 seconds for the
battery to time out.
5. Remove the foot frame cover (A) (see figure 4-19 on page 4-39).
6. Remove the cover (B) from the bed right side of the foot hilow column (C).
7. Disconnect the cable (D) from the brake detection switch (F).
8. Open the cable track located under the foot crossbar on the frame, and
remove the brake detection switch cable.
9. Remove the screw (E) securing the brake detection switch (F) to the frame.
10. Remove the brake detection switch (F).
Replacement
1. Perform the removal procedure in reverse order.
2. To make sure the CareAssist® Bed operates correctly, do the “Function
Checks” on page 2-5.

Hill-Rom CareAssist P1170 Specifications

General

Model	CareAssist P1170
Type	Hospital Bed
Weight Capacity	500 lbs (227 kg)
Trendelenburg Position	Yes
Reverse Trendelenburg Position	Yes
Battery Backup	Yes
Frame Material	Steel
Knee Gatch	Yes
Head Section	Adjustable
Foot Section	Adjustable
CPR Release	Yes
Overall Width	39 in
Height Range	15 in to 30 in
Side Rails	Yes
Power Source	Electric
Mattress Type	Foam or Air
Patient Controls	Yes
Wheels	Locking Casters
Warranty	Varies
Overall Length	88 inches (223.5 cm)
