4.21 Head Hilow Column (B Model and Newer Beds)
Chapter 4: Removal, Replacement, and Adjustment Procedures
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 4 - 63
4
4.21 Head Hilow Column (B Model and Newer Beds)
Tools required: 13 mm socket
Ratchet
Extension
(2) Jack stands
T25 Torx®
1
screwdriver
T15 Torx® screwdriver
Wire cutters
Antistatic strap
Removal
1. Set the brakes.
2. Remove the headboard.
3. Raise the head section to the full up position.
WARNING:
Do not work under an unsupported load. Install appropriate supports.
Failure to do so could cause personal injury or equipment damage.
4. Place the jack stands under the articulating frame.
5. Lower the articulating frame onto the jack stands.
SHOCK HAZARD:
Unplug the bed from its power source. Failure to do so could cause
personal injury or equipment damage.
6. Unplug the bed from its power source. Let the bed sit for 60 seconds for the
battery to time out.
7. Remove the two screws (A) from the retainers (C) (see figure 4-28 on page
4-64).
8. Remove the retainers (C).
9. Remove the three screws (D) that attach the power supply cover (E) to the
power supply (F).
10. Remove the power supply cover (E).
1. Torx® is a registered trademark of Acument Intellectual Properties, LLC.

Hill-Rom CareAssist P1170 Specifications

General

Model	CareAssist P1170
Type	Hospital Bed
Weight Capacity	500 lbs (227 kg)
Trendelenburg Position	Yes
Reverse Trendelenburg Position	Yes
Battery Backup	Yes
Frame Material	Steel
Knee Gatch	Yes
Head Section	Adjustable
Foot Section	Adjustable
CPR Release	Yes
Overall Width	39 in
Height Range	15 in to 30 in
Side Rails	Yes
Power Source	Electric
Mattress Type	Foam or Air
Patient Controls	Yes
Wheels	Locking Casters
Warranty	Varies
Overall Length	88 inches (223.5 cm)
