4.37 Auxiliary Outlet
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 110 CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4)
4.37 Auxiliary Outlet
Tools required: T20, T25, and T35Torx®
1
screwdrivers
Wire cutters
Multimeter
Removal
1. Set the brakes.
2. Raise the bed to the full up position.
3. Raise the head, knee, and foot sections to the full up position.
4. Raise the left side siderails to the up and locked position.
SHOCK HAZARD:
This bed has two power cords. Failure to disconnect both power cords
from their power source could cause injury or equipment damage.
5. Disconnect both power cords (A and B) from their power source. Let the
bed sit for 60 seconds so the battery times out (see figure 4-48 on page
4-111).
6. Remove the headboard.
7. Remove the screw (C) that attaches the cable clamp (D) to the head-end
crosstube (E).
8. Remove the cable clamp (D) from the outlet power cord (A).
9. Remove the cable ties that hold the outlet power cord to the wire guide (F)
and intermediate frame (G).
1. Torx® is a registered trademark of Acument Intellectual Properties, LLC.

Hill-Rom CareAssist P1170 Specifications

General

Model	CareAssist P1170
Type	Hospital Bed
Weight Capacity	500 lbs (227 kg)
Trendelenburg Position	Yes
Reverse Trendelenburg Position	Yes
Battery Backup	Yes
Frame Material	Steel
Knee Gatch	Yes
Head Section	Adjustable
Foot Section	Adjustable
CPR Release	Yes
Overall Width	39 in
Height Range	15 in to 30 in
Side Rails	Yes
Power Source	Electric
Mattress Type	Foam or Air
Patient Controls	Yes
Wheels	Locking Casters
Warranty	Varies
Overall Length	88 inches (223.5 cm)
