4.38 SafeView™ Alerts
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 114 CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4)
4.38 SafeView™ Alerts
Tools required: T25 Torx®
1
screwdriver Wire cutters
Needle nose pliers Antistatic strap
Weight, 50 lb (23 kg) minimum
Removal and Replacement
1. Set the brakes.
2. Fully extend the foot section.
3. Raise the bed to the high position.
4. Raise the head section to the highest position.
SHOCK HAZARD:
Failure to unplug the bed from its power source could cause injury or
equipment damage.
5. Unplug the bed from its power source. Let the bed sit for 60 seconds so the
battery will time out.
6. Remove the two screws (A) from the retainers (C) (see figure 4-51 on page
4-115).
7. Remove the retainers (C).
8. Remove the three screws (D) that attach the power supply cover (E) to the
power supply (F).
9. Remove the power supply cover (E).
1. Torx® is a registered trademark of Acument Intellectual Properties, LLC.

Hill-Rom CareAssist P1170 Specifications

General

Model	CareAssist P1170
Type	Hospital Bed
Weight Capacity	500 lbs (227 kg)
Trendelenburg Position	Yes
Reverse Trendelenburg Position	Yes
Battery Backup	Yes
Frame Material	Steel
Knee Gatch	Yes
Head Section	Adjustable
Foot Section	Adjustable
CPR Release	Yes
Overall Width	39 in
Height Range	15 in to 30 in
Side Rails	Yes
Power Source	Electric
Mattress Type	Foam or Air
Patient Controls	Yes
Wheels	Locking Casters
Warranty	Varies
Overall Length	88 inches (223.5 cm)
