Hill-Rom CareAssist P1170 User Manual

Base Frame—A Model Beds
Chapter 5: Parts List
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 5 - 11
5
Table 5-2. Base Frame—A Model Beds
Item Number Part Number Quantity Description
1 VI0610A 8 Screw
2 CA0010 2 Cover, hilow column, painted
3 S30545K 4 Cover
4 71649 1 Label, brake/steer position, lh
71788 1 Label, brake/steer position, rh
5 CA0011 1 Foot end brake cover
6 S30528K 4 Caster support
7 RO0110A 1 Caster, brake/steer
8 RO0108A 2 Caster, brake, anti-static
9 VI0326 8 Screw
10 VI0361 4 Nut
11 VI0020 4 Bolt
12 CAG002 1 Brake/steer pedal
13 S30527K 2 Plastic bushing
14 F11203A 1 Brake bar
15 VI0616A 16 Washer
16 72992 1 Power cord
17 VI0093 2 Screw
18 QD0663 2 Washer
19 71082 2 Bumper
20 S30526K 2 Base plate
21 S30283B 2 Accessory socket
22 71438 2 Adapter, IV pole
23 CA0012 1 Head end brake cover
24 CA0003 1 Brake rod, head
25 CA0006 1 Base frame assembly
26 VI0613A 4 Screw
27 AG0034 1 Brake detection switch
28 S30531K 8 Main bearing
29 AG0036 2 Hilow column
30 VI0613A 2 Screw

Hill-Rom CareAssist P1170 Specifications

General

Model	CareAssist P1170
Type	Hospital Bed
Weight Capacity	500 lbs (227 kg)
Trendelenburg Position	Yes
Reverse Trendelenburg Position	Yes
Battery Backup	Yes
Frame Material	Steel
Knee Gatch	Yes
Head Section	Adjustable
Foot Section	Adjustable
CPR Release	Yes
Overall Width	39 in
Height Range	15 in to 30 in
Side Rails	Yes
Power Source	Electric
Mattress Type	Foam or Air
Patient Controls	Yes
Wheels	Locking Casters
Warranty	Varies
Overall Length	88 inches (223.5 cm)
