Hill-Rom CareAssist P1170 User Manual

Base Frame—B and C Model Beds
Chapter 5: Parts List
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 5 - 35
5
Table 5-13. Base Frame—B and C Model Beds
Item Number Part Number Quantity Description
1 VI0610A 8 Screw
2 132180 2 Cover, column
3 S30545K 4 Cover
4 71649 1 Label, brake/steer position, lh
71788 1 Label, brake/steer position, rh
5 CA0011 1 Foot end brake cover
6 S30528K 4 Caster support
7 RO0110A 1 Caster, brake/steer
8 RO0108A 3 Caster, brake, anti-static
9 VI0326 8 Screw
10 VI0361 4 Nut
11 VI0020 4 Bolt
12 135216 1 Brake/steer pedal
13 S30527K 2 Plastic bushing
14 F11203A 1 Brake bar
15 VI0616A 16 Washer
16 133167 1 Power cord, NEMA5-15P, 10A/250V
133168 1 Power cord, 2073:2000, 10A/250V
133169 1 Power cord, BS1363/A, 10A/250V
133170 1 Power cord, CEE 7/7, 10A/250V
133171 1 Power cord, AS3112 (Clear), 10A/250V
133172 1 Power cord, GB2099.1-’96, 10A/250V
133173 1 Power cord, BS546, 10A/250V
133174 1 Power cord, CE1,23-16-V11, 10A/250V
133175 1 Power cord, NEMA5-15P, 13A/100V
133176 1 Power cord, NEMA5-15P, 13A/110V
134752 1 Power cord, SB107-2-D1-10A,
10A/250V
17 VI0093 2 Screw
18 QD0663 2 Washer
19 71082 2 Bumper
20 S30526K 2 Base plate

Hill-Rom CareAssist P1170 Specifications

General

Model	CareAssist P1170
Type	Hospital Bed
Weight Capacity	500 lbs (227 kg)
Trendelenburg Position	Yes
Reverse Trendelenburg Position	Yes
Battery Backup	Yes
Frame Material	Steel
Knee Gatch	Yes
Head Section	Adjustable
Foot Section	Adjustable
CPR Release	Yes
Overall Width	39 in
Height Range	15 in to 30 in
Side Rails	Yes
Power Source	Electric
Mattress Type	Foam or Air
Patient Controls	Yes
Wheels	Locking Casters
Warranty	Varies
Overall Length	88 inches (223.5 cm)
