Hill-Rom CareAssist P1170 User Manual

Head Siderail—D Model and Newer Beds
Chapter 5: Parts List
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 5 - 83
5
Table 5-31. Head Siderail—D Model and Newer Beds
Item Number Part Number Quantity Description
1 72290 1 Label, blank, speaker cover
2 72862 4 or 8 Screw hi-lo
3 71090 1 Speaker cover
4 71091 1 Gasket, cover
5 70746 1 Speaker
6 28562 4 Nut
7 128804 1 Siderail, rh (scale beds)
129656 1 Siderail, lh (scale beds)
71019 1 Siderail, rh (non-scale beds)
71062 1 Siderail, lh (non-scale beds)
8 71536 1 Membrane switch, nurse call
71795 1 Label, nurse call, blank
9 4214102 4 Screw
10 131573 1 Scale display, with bed exit, rh
128803 1 Scale display, with bed exit, lh
131572 1 Scale display, without bed exit, rh
131571 1 Scale display, without bed exit, lh
138231 1 Scale display, PPM, rh
138230 1 Scale display, PPM, lh
138233 1 Display, PPM only, rh
138232 1 Display, PPM only, lh
155086 1 Scale display, with bed exit and Navi-
Care, rh
155088 1 Scale display, with bed exit and Navi-
Care, lh
155089 1 Display, with bed exit and NaviCare, no
scale, rh
155090 1 Display, with bed exit and NaviCare, no
scale, lh
11 131724 1 Display axel, weldment, short, lh
129658 1 Display axel, weldment, long, rh
12 129441 1 Pivot insert

Hill-Rom CareAssist P1170 Specifications

General

Model	CareAssist P1170
Type	Hospital Bed
Weight Capacity	500 lbs (227 kg)
Trendelenburg Position	Yes
Reverse Trendelenburg Position	Yes
Battery Backup	Yes
Frame Material	Steel
Knee Gatch	Yes
Head Section	Adjustable
Foot Section	Adjustable
CPR Release	Yes
Overall Width	39 in
Height Range	15 in to 30 in
Side Rails	Yes
Power Source	Electric
Mattress Type	Foam or Air
Patient Controls	Yes
Wheels	Locking Casters
Warranty	Varies
Overall Length	88 inches (223.5 cm)
