3.2 Intended use
The product described is a battery-powered rotary hammer. It is designed for hammer drilling in concrete
and masonry, for drilling in steel, wood and masonry and for driving and removing screws.
• Use only Hilti lithiumion batteries of the B 22 series with this product.
• Use only Hilti-approved battery chargers to charge these batteries. More information is available from
your Hilti Store or from www.hilti.group
3.3 Lithiumion battery status display
When the lithium-ion battery is used the charge status can be displayed by tapping one of the battery release
buttons.
Status Meaning
4 LEDs light. Charge status: 75 % to 100 %
3 LEDs light. Charge status: 50 % to 75 %
2 LEDs light. Charge status: 25 % to 50 %
1 LED lights. Charge status: 10 % to 25 %
1 LED blinks. Charge status: < 10 %
Indication of the charge status is not possible while the power tool is in operation or immediately after
operation. If the battery charge status LEDs flash, please refer to the information given in the Troubleshooting
section.
3.4 Items supplied
Rotary hammer, side handle, depth gauge, operating instructions.
The TE DRS-4-A (01) dust removal module greatly reduces dust emissions and is available as an accessory.
Other system products approved for use with this product can be found at your local Hilti Store or at:
www.hilti.group
4 Technical data
4.1 Rotary hammer
TE 4A22
Weight in accordance with EPTA Procedure 01 including B22⁄8.0 battery
3.9 kg
Single impact energy in accordance with EPTA procedure 05/2009
2 J
Drilling diameter range in concrete/masonry (hammer drilling)
4 mm … 28 mm
Drilling diameter range in wood (solid)
3 mm … 20 mm
Drilling diameter range in metal (solid-head drill bit)
3 mm … 10 mm
4.2 Noise information and vibration values in accordance with EN 62841
The sound pressure and vibration values given in these instructions were measured in accordance with a
standardized test and can be used to compare one power tool with another. They can also be used for a
preliminary assessment of exposure.
The data given represent the main applications of the power tool. However, if the power tool is used for
different applications, with different accessory tools, or is poorly maintained, the data can vary. This can
significantly increase exposure over the total working period.
An accurate estimation of exposure should also take into account the times when the power tool is switched
off, or when it is running but not actually being used for a job. This can significantly reduce exposure over
the total working period.
Identify additional safety measures to protect the operator from the effects of noise and/or vibration, for
example: maintaining the power tool and accessory tools, keeping the hands warm, organization of work
patterns.
