Technical data
Rated power 600 W
Rated voltage 120 V
Rated current input 5.2 A
Mains frequency 50–60 Hz
Weight of tool 2.3 kg / 5.1 lbs (TE2)
2.4 kg / 5.3 lbs (TE2-S)
2.6 kg / 5.7 lbs (TE2-M)
Dimensions (l×h×w) 344×200×79 mm / 13.5×7.9×3.1 in (TE2 / TE2-S)
359×200×79 mm / 14.1×7.9×3.1 in (TE2-M)
Minimum distance between wall and hole drilled 30 mm (1.2 in)
No load speed 0– 930 r.p.m. ( TE2 / TE2-S)
(in 1st gear TE2-M)
0–2200 r.p.m. (in 2nd gear TE2-M)
Hammering speed:
Precision hammering action 0–2400 blows/min. (TE2-S / TE2-M)
Full hammering action 0–4600 blows/min (TE2 / TE2-S / TE2-M
Single impact energy Nm (J):
Precision hammering action 0.6 Nm / 0.4 ft lbs (TE2-S / TE2-M)
Full hammering action 1.8 Nm / 1.3 ft lbs (TE2 / TE2-S / TE2-M)
Typical drilling performance in medium-hard B35 8 mm dia.: 500 mm/min (
5
/
16
″ dia.: 19.7 in/min)
concrete 10 mm dia.: 440 mm/min (
3
/
8
″ dia.: 17.3 in/min)
12 mm dia.: 340 mm/min (
1
/
2
″ dia.: 13.4 in/min
Typical weighted vibration at the handles ≤ 10 m/s
2
A-weighted Emission Sound Pressure Level (LpA) ≤ 89 dB(A)
A-weighted Sound Power Level (LwA) ≤ 102 dB(A)
Right of technical changes reserved
