HIMA HIMatrix Series Safety Manual

HIMatrix 2 Intended Use
HI 800 023 E Rev. 1.01 Page 11 of 72
Standard Content
EC/EN 61131-2:
2006
Programmable controllers, Part 2
Equipment requirements and tests
IEC/EN 61000-6-2:
2005
EMC
Generic standards, Parts 6-2
Immunity for industrial environments
IEC/EN 61000-6-4:
2006
Electromagnetic Compatibility (EMC)
Generic emission standard, industrial environments
Table 2: Standards for EMC, Climatic and Environmental Requirements
When using the safety-related HIMatrix control systems, the following general requirements
must be met:
Requirement type Requirement content
Protection class Protection class II in accordance with IEC/EN 61131-2
Pollution Pollution degree II in accordance with IEC/EN 61131-2
Altitude < 2000 m
Enclosure Standard: IP20
If required by the relevant application standards (e.g., EN 60204,
EN 15849), the HIMatrix system must be installed in an enclosure of
the specified protection class (e.g., IP54).
Table 3: General requirements
2.3.1 Climatic Requirements
The following table lists the key tests and thresholds for climatic requirements:
IEC/EN 61131-2 Climatic tests
Operating temperature: 0...+60 °C
(test limits: -10...+70 °C)
Storage temperature: -40...+85 °C
Dry heat and cold resistance tests:
+70 °C / -25 °C, 96 h, power supply not connected
Temperature change, resistance and immunity test:
-25 °C / +70 °C und 0 °C / +55 °C,
power supply not connected
Cyclic damp-heat withstand tests:
+25 °C / +55 °C, 95 % relative humidity,
power supply not connected
Table 4: Climatic Requirements
2.3.2 Mechanical Requirements
The following table lists the key tests and thresholds for mechanical requirements:
IEC/EN 61131-2 Mechanical tests
Vibration immunity test:
5...9 Hz / 3.5 mm
9...150 Hz, 1 g, EUT in operation, 10 cycles per axis
Shock immunity test:
15 g, 11 ms, EUT in operation, 2 cycles per axis
Table 5: Mechanical Tests
