2.6 Remote Mode
19
Chapter 2 Model IM3570/ IM3536 Connection and Setting
When you connect a device to an interface and start communication, the mode becomes remote mode
(remote operation state) and the keys on the LCD are disabled.
2.6 Remote Mode
Canceling Remote Mode
All of the keys except are disabled.
Remote Mode State
Procedure
2
Press to return to the normal state
(local state).
1
The measurement screen is redisplayed.
Local State
LCR Measurement Screen
