3.3 GP-IB Connection and Settings (when connected to the Z3000)
24
Connect the GP-IB cable to the GP-IB connector.
3.3 GP-IB Connection and Settings
(when connected to the Z3000)
Connecting the GP-IB Cable
Setting GP-IB
1
Open the SYSTEM screen.
2
Select GP-IB as the interface.
Recommended cable:
9150-02 GP-IB connection cable (2 m)
Open the SYSTEM screen.
Select.
1
Select GP-IB.
2
