Hioki IM3523 - Setting RS-232 C

4.4 RS-232C Connection and Settings (when connected to the Z3001)
42
Setting RS-232C
Procedure
LCR Measurement Screen
1
Interface Settings
You can configure the setting from any of mode, mode and mode.
Press .
2
RS-232C Settings
3
Press to confirm the setting.
4
RS-232C Settings
Select the handshake setting.
No flow control
Hardware (RTS/CTS control)
Software (XON/XOFF control)
Hardware + software
Select the terminator setting.
CR+LF
CR
Select the baud rate setting.
