4.2
USB Settings and Connection
37
Chapter 4 Model IM3533/ IM3533-01/ IM3590 Connection and Setting
The display will vary with the installed options.
4.2 USB Settings and Connection
Setting USB
To connect the instrument to a computer the first time, a dedicated USB driver must be installed.
Before connecting the instrument to the computer, install the USB driver.
The USB driver can be downloaded from the bundled CD, or our web site.(http://www.hioki.com)
The USB driver is compatible with the Windows XP (32-bit version), Windows Vista (32-bit, 64-bit
version), and Windows 7 (32-bit, 64-bit version) operating systems.
Additionally, do not put the computer into the sleep state while the instrument is connected to the
computer.
You can configure the setting from any of mode, mode and mode.
Procedure
LCR Measurement Screen
1
Interface Settings
Using the Z3002
Using the Z3001
Press .
2
USB Setting
Using the Z3000
When an option is connected
To Next Page
